3D Laser Scanning for BWTS & Reverse Engineering
We provide 3D Laser Scanning Services for Ballast Water Treatment System (BWTS) Retrofit, general retrofit and for other reverse engineering applications at several ports around the globe.
Structural Design
Preparation of detailed structural models and drawings accompanied by relevant reporting.
Services offered cover the following:
- Overall weight & COG estimation
- Bill of materials
- Estimation of painting area
- Structural Foundation drawings for Equipment
- Assembly Blocks
- Hull Workshop Drawings
- Nesting Drawings
- Numerical Cutting (NC) Codes
- Profile Production Sketches
Piping & Electrical Design
Services offered cover the following:
- Pipe routing for new systems
- Estimation of piping lengths for costing estimation
- Fabrication drawings / Spool drawings
- Revision of electrical drawings for BWTS retrofit
- System Drawings (Piping, HVAC, electrical cabling)
- Arrangement & Co-ordination Plans
